Upper Primary Mathematics Kit ("U.P.M.K.")

[1] 2 3 4 [ Next»]   Click to Enlarge Kit manual Kit manual along with kit See Enlarge Click to Enlarge Kit box with carton Plastic molded box in Red colour overall size 340mmx340mm x height 110 mm with tolerance +/-5mm and sheet thickness 5mm Two parts and joint with two pines on side all corner round shape and top to bottom taper 10 degree approx and handle for carrying with locking system. Inner side arrange for partition two pieces taper shape plastic strip for partiton and outer side etching. Whole box weight not less than one Kg. As per sample. See Enlarge Click to Enlarge Plastic Strip (Type I) Transparent Perspex sheet or plastic moulded 262 X 20 X 2.7 mm to 3 mm, having 3 holes of dia 5 mm at a distance of 50 mm, 120 mm and 190 mm from one end . 4 slots Of 25 X 5mm with both ends rounded to semi- circle.Location of slots:1st slot:0- 25mm, 2nd slot :70-95mm, 3rd slot: 140- 165mm, 4th slot: 210-235mm Marking should be in black colour. As per sample See Enlarge Click to Enlarge Plastic Strip (Type II) Transparent plastic moulded or Perspex sheet 262 X 20 X 2.7mm to 3mm, having 2 holes of dia 5 mm at a distance of 50mm and 120mm from one end. 3 slots X 5mm width with both ends rounded to semi-circle.Location of slots:1st slot: 0-25mm 2nd slot :70- 95mm 3rd slot :140-235mm Marking should be in black clolour. As per sample See Enlarge Click to Enlarge Half Protractor Transparent, plastic, withdia.96 mm, thickness 2 mm. Double angle marking 0-180 degree. With center hole dia 4mm. on base line. As per Sample See Enlarge Click to Enlarge Full Protractor Marking at place to be 320 degree and 340 degree in place of 220 degree and 240 degree respectively Transparent plastic, with diameter 125mm approx. thickness 2 mm. Double angle marking 0-360degree With center hole dia 4mm. on center point. As per sample See Enlarge Click to Enlarge Fly nut and Screw Mild steel, chromium plated,lenght 15 mm, metric thread (M4), round head washer type.With fly nut. As per sample See Enlarge Click to Enlarge Geo - board / Geo-board pins ABS material,210 X 210 X15mm. One face has grids of 10 mm square 2mm dia X 7mm deep. Corners of each square except boundary corners of the squares i.e. total square 289. other side four rounds with 2.5mm diax 6mm height dowel inbuilt dia. Having 70, 110, 150, 190 space mm each dia. 20 dowels inbulit in each circle and 1 dowel inbulit at centre point. As per sample 2mm dia X length 15mm of aluminum pins with rounded head As per sample See Enlarge Click to Enlarge Rubber bands Standard item assorted size thin rubber band good quality As per sample See Enlarge Click to Enlarge Paper nets for solid geometrical shapes (a) 350 GSM papere, UV/ coated 60 X 60 X 60 mm cube As per sample (b) Cuboid 65 X 65 X 40mm cuboid As per sample (c) Cone Cone with slant height of 120mm and circular based diameter of 80mm As per sample (d) Cylinder Height: 130mm and circular base diameter 60mm. As per (e) Prism Height 100mm, equilateral triangle of sides of 55mm As per sample (f) Pyramid (with triangular base) 4 equilateral triangles of sides 93mm As per sample (g) Pyramid with square base Square base sides of 70mm, equilateral triangle of sides 70mm. As per sample (h) Hexagonal Base Prism Hexagon side 40mm & hexagonal base prism height 120mm. All the shapes plastic coated on both sides As per See Enlarge Click to Enlarge Cut outs of paralleogram Parallelogram Plastic corrugated sheet 3mm thick, blue colour. Lenght 120mm, width 85mm, one angle 75 degree Labeling with black colour. As per sample b) Cut outs of Triangle and Trapezium (parallelogram)" Triangle cut from a Parallelogram As per sample c) Cut outs of Triangle and Trapezium (Rectangle) Trapezium and triangle to form the rectangle Triangles in Parallelogram and rectangle to be of the same size. As per sample d) Two congruent Trapeziums (parallelogram)" Two congruent Trapeziums forming a Parallelogram Each part to be separated As per sample e) Triangle A, B, and C from a parallelogram Parallelogram showing triangle in it. Triangles A and C fitting on triangle B As per sample f) Two congruent Triangles Two congruent Triangles As per sample See Enlarge Click to Enlarge Four equal divisions of a circle Four equal division of a circle all marked with A. Blue colour plastic corrugated sheet of 3mm thickness diameter 160mm. its thickness may be increased to 5mm. All pieces should be cut in the form of sectors. As per b) Six equal divisions of a circle six equal division of a circle, all marked with B As per sample c) Eight equal divisions of a circle Eight equal divisions of a circle all marked with C. As per sample d) Twelve equal divisions of a circle Twelve equal divisions of a circle all marked with D. As per sample e) Sixteen equal divisions of a circle Sixteen equal divisions of a circle all marked with E. As per sample f) Two equal parts of a circle Two equal parts of a circle As per sample g) Three equal divisions of a circle Three equal divisions of a circle. Note- Thickness of each sheet be increased to 5mm As per sample See Enlarge Click to Enlarge Plastic Cubes ABS plastic cubes with sides 20 mm accurate size, 5 mm to 8mm diaholes with depth of 5 mm on five faces, Sixth face will have a peg to push fit into the holes. As per sample See Enlarge Click to Enlarge Counters Plastic dia 20mm (whose one side is blue and other side is red) As per sample See Enlarge Click to Enlarge Counters of different colours Plastic, 20 mm diameter X 2mm thickness. Different 4 colours two of each colour. Red,Blue,Yellow and Green As per sample See Enlarge [1] 2 3 4 [ Next»] Go to Top
